1000FT Cat5e Heavy Duty, UTP, Direct Burial, Outdoor Gel Filled Bulk Cable
Price:
$205.99
Dispensing Type/Color
Quantity
add to cart

Item #3    p/n DC-1020


HEAVY DUTY CABLE over 1/4 inch thick
UV Resistant
Direct Burial (Gel Filled)
Unshielded - UTP

Has 2 jackets plus the gel fill. Amazing water proof potential!

Use for either above-ground or in-ground.

As low as $196.99


Details:

 1000FT Cat5e  Heavy Duty,  Unshielded, UV-Resistant & Direct Burial Gel Filled Outdoor Bulk Cable

Prices:

1 Reel in a Box        $205.99ea
2-4 Reels                  $199.99ea
5 -9 Reels                  $197.99ea

10 or More Reels    $196.99ea



Details:

  • HEAVY DUTY CABLE over 1/4 inch thick. Accepts standard sized RJ45s... but very snug fit
  • 2nd PVC jacket layer inside cable for additional water proofing
  • Meets TIA/EIA 568B.2 or Greater Networking Standard
  • Supports 10/100/1000Mbps (Gigabit Ethernet)
  • UTP (Unshielded Twisted Pair)
  • 24AWG Solid Copper Core
  • UV Stabilized PE Jacket
  • Gel Filled for Direct Burial Applications
  • Ripcord
  • Reel in a box
  • Shireen  P/N DC-1020
  • Made in China



Electrical Specification



Velocity of Propagation

68%

Capacitance @ 1 KHz

15 pF/ft





Standard

TIA/EIA 568B.2 or greater



Cable Construction



Center Conductor

Solid bare copper(BC) 24awg .02in .51mm

Insulation

High Density Polyethylene (HDPE) .04in .93mm

Color

Blue/  White w/blue stripe

Orange/ White w/orange stripe

Green/  White w/green stripe

Brown/ White w/brown stripe

Sheath Material & Thickness

Cable Diameter

PE with Grease  .024 in  .60mm

.27in  6.90mm

Assembly

Ripcord



Mechanical And Environmental Specifications



Cable weight

16.3 kgs/1000ft

Operating Temperature Range

-49F to +149F  (-45C to +65Celcius)



Electrical Characteristics



Frequency, MHZ

1

4

8

10

31.25

62.5

100

Attenuation, dB

2.0

4.1

5.8

6.5

11.7

17

22

Structured Return Loss (SRL), dB

20

23

25.4

25

23.6

21.5

20.1

NEXT, dB

65.3

56.3

51.8

50.3

42.9

38.4

35.3

ELFEXT, dB

63.8

51.7

45.7

43.8

33.9

27.8

23.8


New P/N  DC-1020  (Old Product# C5E-1000-UTP-DB )
